Product description

China Aidun Electrical produce “SOLARSON”brand HR17B series NH1 Horizontal Fuse Switch Disconnectors 250A are specifically designed to be used with NH1 fuse links. All energised metal parts are fully protected against accidental contact. These are manually operated switches and the making and breaking is dependent on the speed of the operation

Technical data

  • Rated current of fuses :40A,50A,63A,80A,100A,125A,160A,200A,250A
  • Rated voltage:400, 500 and 690 V a.c/dc
  • Interupting capacity:DC 50kA
  • Operating class: gG/gL,aM,aR
  • According to IEC/EN60269 and IEC/EN60947
No. Product type Rated  Voltage (V) Rated current(A) Compatible Fuse Link Size Overall dimension(mm)
18060 HR17B-160 500/690 160 RT16-00,NT00, NH00C Refer to for detailed data
18061 HR17B-250 500/690 250 RT16-1,NT1,NH1
18062 HR17B-400 500/690 400 RT16-2,NT2,NH2
18063 HR17B-630 500/690 630 RT16-3,NT3,NH3
